Wiegand TVR-6-Effect with High Concentrator Evaporator

Location

Spain

orCall +494072548640

Specifications

ManufacturerWiegand
Model6-Effect-TVR with High Concentrator Evaporator
Year1983
ConditionUsed
Serial Number2502-75182.01
Stock Number927
Type of MachineEvaporator
Condition StatusUsed Good Condition
Stages6
Capacity input (whey)20.000 kg/h (6% TS)
Water Evaporation17.930 kg/h
Concentrate (whey)2.070 kg/h (50% TS)

Description

Used Wiegand TVR-6-Effect + High Concentrator Evaporator, previously used for whey. Still mounted inside the factory in Spain.


1.Effect

Diameter of the stage 1.050 mm

Diameter of the tubes 31 mm

Length of the tubes 10.000 mm


2.Effect

Diameter of the stage 1.050 mm

Diameter of the tubes 31 mm

Length of the tubes 10.000 mm


3.Effect

Diameter of the stage 1.000 mm

Diameter of the tubes 31 mm

Length of the tubes 10.000 mm


4.Effect

Diameter of the stage 600 mm

Diameter of the tubes 41 mm

Length of the tubes 10.000 mm


5.Effect

Diameter of the stage 450 mm

Diameter of the tubes 41 mm

Length of the tubes 10.000 mm


6.Effect

Diameter of the stage 400 mm

Diameter of the tubes 41 mm

Length of the tubes 10.000 mm


High Concentrator

Diameter of the stage 400 mm

Diameter of the tubes 41 mm

Length of the tubes 10.000 mm


Additional features:

Including:

- High Concentrator.

- Pumps.

- Valves.

- MCC Panel with simple on / off controls.

- Dismantling and loading is included in the price.
