Rotary positive displacement pump / Lobe pump - APV CLP/2/036/20

The APV Cleanline CLP/2/036/20 is a positive displacement rotary lobe pump with sanitary design which can handle dairy products (e.g., yoghurt, quark, curd and butter), foodprocessing, beverage, cosmetics, pharmaceutical and fine chemicals industries. This pump is perfect for managing all kinds of fluid, of either low or high viscosity, as well as for filtering and bottling applications. Products containing fragile solids such as curd can be pumped without damage thanks to the specially designed lobes. Tri-lobe stainless steel lobes / rotors. Nominal displacement: 0,360 liter per revolution. Maximum nominal capacity: 15 m3/h. Inlet connection: 2''. Outlet connection: 2''. Maximum product pressure: 10 bar. Maximum pump speed: 720 rpm. Maximum temperature: 110 °C. The pump is used in a dairy for product pumping. The current motor with this pump is 4 kW - 1.440 rpm - 220 / 380 V - 50 Hz - 16,3 / 9,4 A and the lobe speed is converted to 270 rpm, which results in a capacity of 5,5 m3/h. Pump and motor mounted on a stainless steel frame.
