Universal Machine Stephan UM/SK 60 E

Location

Hamburg, Germany

orCall +494072548640

Specifications

ManufacturerStephan
ModelUM/SK 60 E
Year1995
ConditionUsed
Serial Number722.110.01
Stock Number1158
Type of MachineUniversal machine
Volume60 liter
Batch size40 liter batch max
Capacity± 200 kg/h
Operating temperature95 - 127 °C
Dimensions180 x 70 x 160 cm
Weight300 kg

Description

Stephan UM/SK 60 E Universal Machine for the production of processed cheese, convenience products, vegan spreads and confectionery. Mounted on a stainless steel frame. The bowl is equiped with a double jacket for heating/cooling on the jacket, 2x direct steam injection nozzles for direct injection of (culinair) steam inside the product, temperature sensor inside the product, cutting blade, maximum working pressure in the bowl -/ -1 bar (protected with overpressure valve), maximum temperature in the bowl 95 °C, maximum temperature in the jacket 95 °C, vacuum connection on the bowl, dearation connection on the bowl, infeed connection on the lid with a hopper with a manual valve for adding powders, mounted on the lid a scraper agitator for the wall, electric driven (0,37 kW - n2: 24 rpm), 1 manual tightening clamp, pneumatic outfeed valve for the product, so not needed to tilt the bowl for empyting. Main motor for the cutting knife: 400 Volt - 50 Hz - 5,5 / 7,5 kW - 1.415 / 2.880 rpm - 12,4 / 16,2 Amp. Original stainless steel Stephan main control panel with relay controls and buttons. Manual and spare parts list available in German language.
